ASA60012VRH

ASA60012VRH – swing gate motor – right hand (12 volts – 5.0 metres)

$607.00

In stock

Description

The big, long ASA600 has been used in so many solar kit farm gates that we have lost count. The reason? Price and reliability. The ASA600 is great value for money with a quality Italian 12 volt motor and tried and tested engineering. Marry that to our proven solar technology and you have a winning combination. Manufactured in Italy the ASA600 is a powerful 12 volt swing gate electro mechanical operator suitable for gates to 5 metres wide. It is a self locking operator with key operated manual override although you would still use an electric gate lock as the ASA600 is typically installed on gates wider than 2.0 metres where the electric gate lock is necessary. One of the benefits of the 12 volt motor is the ability to use battery backup meaning you may never have to use the manual override key.

It is possible to use a variety of control boards to control the ASA600 and we have developed some excellent solar powered applications. The factory designed board is the ID200 and can be used in a number of different modes and as a one or two motor controller complete with code hopping receiver. Another option is the MCE12E control board with an intuitive screen that asks you questions to program. Both available as double gate kits with great kit savings

ASA600 Install Manual

Download

Additional information

Weight 12 kg
Motor Voltage

12 volts DC

Standby Current

0mA

Maximum Current

2.0A

Motor Power

70W

Maximum Thrust

1500Nm

Opening Time

31.0 seconds to 90 degrees

Maximum Gate Width

5000mm

Duty Cycle

90%

Height (mm)

195mm

Width (mm)

90mm

Length (mm)

970mm

Weight (kg)

7.0 Kg

IP Rating

IP54
