ELECTRADROP

Description

LOCINOX ELECTRADROP GATE LOCK
Electric 24 V dropbolt with 115 mm throw for safe locking of automated gates. By securing your gate with an Electradrop you disburden the electric gate motors.
Vandal resistant, powdercoated aluminium housing
Easy mounting with Quick-Fix
To be connected to the warning light on automated gates (min 3 sec prewarning signal)
Mechanical release possible (by key) in case of emergency or power failure
Fitted with relay for dropbolt detection
Obstacle detection with automatic stop of the dropbolt
Throw: 115 mm
Dropbolt diameter: 20 mm
For gate profiles: 40 mm or more
Vertical mounting
Consumption: 25 W / Standby: 0,2 W
5 m cable included
Included: 3012-37-STD cylinder
