BULL424SW

BULL424SW – Sliding gate motor with logic control. (24 volt – 400kg)

$1,260.00

SKU 1-20011 Category - Tags ,

Out of stock

Description

BULL424SW

24 Vdc | intensive use

24 Vdc gear motor for intensive use with integrated control unit and virtual encoder | Switching power supply 115/230 Vac which reduces energy consumption and ensures a long lifespan of the actuator | Control unit with trimmers and dip-switches | The virtual encoder enables optimal management of slowing-down phases, movement tracking (STC system) and torque management in relation to the position of the gate, guaranteeing maximum safety | Operation guaranteed even in the event of a power supply failure through batteries that can be perfectly integrated in the motor (2 x 1.2 Ah) | Anti-crushing system with amperometric obstacle detection | Designed for the connection of the X.BE accessory in order to be integrated with KNX domotics installations and the programming through the app BeUP and the interface PRO.UP

Reinforced foundation plate Dima included. Dimensions 326×164.5×2 mm, motor fixing distance 301×75 mm, 4 holes Ø 8.5 mm

BULL424SW - Install Manual

Download

BULL424SW - Brochure

Download

Additional information

Weight 12 kg
Motor Voltage

24 volts DC

Standby Current

8mA

Maximum Current

0.4A

Motor Power

80W

Maximum Thrust

428N

Operating Speed

11 Metres per minute

Maximum Gate Weight

400 Kg

IP Rating

IP44

Height (mm)

330mm

Width (mm)

140mm

Length (mm)

326mm

Weight (kg)

10.2 Kg

Duty Cycle

80%
